The Main Roadway DSJ Belt Conveyor is a telescopic belt conveyor primarily used for mechanized coal transportation in mining faces. Designed for use within an inclination range of -4° to +4°, it is suitable for transportation in mining district entries or roadway development.
Key features include:
Telescopic Capability: Utilizes a storage belt device and a belt retracting/releasing device to extend or shorten the body as needed, adapting to varying working face lengths.
Simple Structure: Non-fixed parts employ quick-release brackets without bolts, facilitating easy disassembly, assembly, and operation, reducing labor intensity.
Strong Adaptability: Intermediate detachable brackets can be floor-mounted or suspended, accommodating different roadway floor conditions.
Efficient Transportation: Effectively enhances entry transportation capacity, accelerating mining and development progress.
Technical parameters vary; for example, model DSJ65/20/2×30 has a conveying capacity of 200t/h, belt width 650mm, belt speed 1.63m/s, conveying length 600m, roller diameter 450mm, idler diameter 89mm, storage belt length 50m, tail length 12m, overlapping gauge 900mm, installed power 2×30kW. In terms of working principle, the DSJ belt conveyor is similar to ordinary belt conveyors but adds a storage belt device and a belt retracting/releasing device for telescopic function. Movement of the trolley allows the belt to enter or exit the storage device, enabling tail section telescoping. In summary, the DSJ belt conveyor plays a vital role in coal mine transportation. Its telescopic capability and efficiency make it an ideal supporting equipment.
