Scraper Conveyor Chain Scraper Chain Scraper Conveyor Parts Cast Stone Scraper Conveyor Chain
Chain Installation
1) Pass the connected chain around the drive sprocket, threading 6~7m beneath the drive head and transition section.
2) Extend chain along floor to tail end. Tilt attached scrapers to enter lower trough.
3) Place connection/transition troughs over tilted chain scrapers. Connect one end to drive transition section, the other to transition trough. Straighten chain into lower trough. Install trough connection pins. Assemble subsequent troughs to tail drive.
4) Thread chain beneath tail drive, around sprocket onto trough deck. Assemble upper chain section to drive head.
