Mining idlers are crucial components of belt conveyors.

I. Structure and Composition

1. Shell

The shell of mining idlers is typically made from high-quality steel. For instance, some idler shells use high-strength seamless steel tubes known for excellent wear resistance and compressive strength. The tube wall thickness is precisely calculated to withstand the weight of the conveyor belt and its load, while resisting potential impacts and squeezing in complex mine environments.

2. Bearings

Bearings are key components. High-precision deep groove ball bearings or tapered roller bearings are generally selected. Deep groove ball bearings provide stable rotational support, suitable for light to medium load conditions. Tapered roller bearings offer superior load capacity, especially for idlers that may bear significant lateral forces, such as those at conveyor belt turns.

3. Sealing Device

Sealing is critical for mining idlers. A labyrinth seal structure is often used, consisting of multiple sealing rings forming complex sealing paths. This effectively prevents dust, moisture, and other contaminants in the mine from entering the idler interior, protecting bearings and other components from corrosion and extending service life.

II. Functional Features

1. Supporting the Conveyor Belt

The primary function is to support the conveyor belt and its load. In transportation systems of coal mines, metal mines, etc., conveyor belts can stretch several kilometers. Idlers are evenly distributed under the belt at intervals (e.g., 1.5 - 3 meters in main coal mine roadways), lifting the belt to maintain stable operation, preventing excessive sag due to its own weight and the load, ensuring smooth material transport.

2. Reducing Friction

Idler rotation significantly reduces friction between the conveyor belt and the supporting structure. High-quality bearings ensure smooth idler rotation. As the belt runs, idlers roll with its movement instead of sliding, lowering running resistance and energy loss. In large-scale mine transportation systems with long distances and heavy loads, good friction reduction significantly saves electrical energy and reduces operating costs.

3. Adapting to Harsh Environments

Mine environments are harsh, with heavy dust, high humidity, and sometimes corrosive gases. Mining idlers are specially designed for these conditions. The shell's anti-corrosion coating prevents rust and corrosion, while sealing devices block dust and moisture. Even in high-humidity mine tunnels, such as deep mining operations, idlers function reliably, ensuring conveyor system dependability.

III. Classification

1. By Purpose

Carrying Idlers: Primarily bear the weight of the belt and material, constituting the largest quantity. Their structure focuses on high-strength support, typically with a larger diameter to evenly distribute pressure. Return Idlers: Support the return section of the belt (without material). Load is relatively lighter but still ensures smooth belt operation, preventing issues like belt deviation during return. Self-Aligning Idlers: Automatically adjust the belt's position when deviation occurs, bringing it back to the correct track. They have a special structure, often with flanges or a rotatable design.

2. By Structural Form

Trough Idlers: Shaped with a concave center and convex sides. Suitable for bulk material transport (coal, ore, etc.), keeping material centered on the belt, preventing spillage, and improving efficiency. Flat Idlers: Cylindrical shape, used mainly on straight sections for flat support, ensuring smooth running, especially near loading/unloading points.
